  • 5km wifi remote module tunnel construction/Marine farm wireless video scheme

    2023-04-20 496

    5km wifi remote module tunnel construction/Marine farm wireless video scheme


    Wireless tunnel construction monitoring project, 13 monitoring points of 6km tunnel, wireless bridge relay transmission, landscape complementary system power supply


    Industry background


    Tunnel construction is a difficult and dangerous project. How to ensure the safe and efficient construction is the subject that the person in charge of tunnel construction project always faces. Using video surveillance system is an effective way to improve tunnel construction. However, because the internal environment of tunnel construction project is quite complex, the access of many construction personnel, vehicles and excavators brings certain difficulties to the wiring construction. Therefore, with the continuous development of wireless technology, 5km wifi remote module wireless video monitoring has gradually become the mainstream choice of tunnel construction monitoring in recent years.

    5km wifi remote module tunnel construction/Marine farm wireless video scheme

    The total length of the tunnel is 6 kilometers, and the wireless video monitoring system was selected in the construction process. Tengyuan Zhituo is mainly the equipment supplier of the wireless monitoring system and the technical guidance of the system erection.


    The tunnel is 6km long and divided into five working faces. The project requires to monitor the situation of the five working surfaces through wireless transmission of 5km wifi remote module, and transmit the monitoring video to the project department outside the tunnel. Since there are two project departments in charge of the project, the surveillance video of the 1# inclined well will be transmitted to one branch, and the surveillance video of the 2# inclined well will be transmitted to the second branch. In addition, the project needs to support the remote monitoring of the headquarters monitoring center, so the monitoring system of the two project branches needs to be connected to the Internet to maintain the 10M upscaling speed


    Design aspiration and rationale


    According to the project requirements, the manufacturer of 5km wifi remote module decided to use CWS2203(built-in 18DB dual-polarization directional antenna) in the wireless monitoring system to ensure the transmission of stable, high-quality surveillance video images, and external dual-polarization omnidirectional antenna. Since there is an obstacle between Hole No. 2 and the monitoring center, we conducted two relays on the top of the mountain to the monitoring center.


    The tunnel construction site is located in a remote area and it is difficult to obtain electricity. The solar landscape complementary power supply system is adopted to provide stable and sufficient power for the wireless monitoring system.


    On-site installation of equipment

    Before leaving the factory, all parameters of 5km wifi remote module will be adjusted according to customer requirements, and equipped with installation and debugging instructions. Generally only need to install the equipment power supply can be used. If the customer wants to modify the parameters, you can contact our technical staff and modify the parameters with the help of our technical staff.



    The wireless transmission scheme of 5km wifi remote module of Qingdao breeding farm is used for wireless monitoring of Marine breeding farms. The HD infrared camera of 720P network is used for wireless transmission of power supply of 5km landscape complementary system


    Industry background

    The layout and installation of video surveillance system often face various problems caused by wiring construction and cost. In order to solve these problems, wireless monitoring equipment appears in the historical moment, simple, fast, efficient wireless monitoring system brings new feelings to users.


    Demand analysis

    The economic value of seafood has increased in recent years, and a Marine farm has been stolen. However, because it is bred at sea, wireless video surveillance cannot be installed using traditional methods, causing headaches for users.


    This project has a total of 27 monitoring points, all using 720P network high-definition infrared cameras, comprehensive coverage of the entire farm, remote transmission distance of 5 kilometers.


    The 5km wifi remote module manufacturer is the supplier and technical guide of the wireless video monitoring system of this project.


    Design aspiration and rationale

    According to customer requirements, the bitstream of each surveillance video should be at least 4MBPS to ensure the transmission of stable and high-quality surveillance video images. Therefore, it is decided to use CSW2203 series wireless as the system transmission: The switch is integrated with a front-end camera, which is then transmitted to the monitoring room through a 5km wifi remote module. The surveillance video will be stored in the hard disk video recorder and also displayed on the monitoring screen.


    On-site installation

    The farm adopts wireless monitoring system, which has good practicability and economy. Outdoor rain and dust proof design, wide voltage power supply, support solar power supply; Simple construction and convenient maintenance.


    When the 5km wifi remote module leaves the factory, the software has been debugged, and the user only needs to power on to complete the physical connection when installing the hardware. No cumbersome wiring, easy to secondary maintenance, maintenance only by a single point of investigation set.
